Product Summary
The ATTINY2313-20SU is a low-power CMOS 8-bit microcontroller based on the AVR enhanced RISC architecture. By executing powerful instructions in a single clock cycle, the ATTINY2313-20SU achieves throughputs approaching 1 MIPS per MHz allowing the system designer to optimize power consumption versus processing speed. The AVR core combines a rich instruction set with 32 general purpose working registers.
Parametrics
Absolute maximum ratings: (1)Speed (MHz): 10 MHz; (2)Power Supply: 2.7 - 5.5 V; (3)Package: 20P3; (4)Operation Range: -40°C to 85°C.
Features
Features: (1)Utilizes the AVR RISC Architecture; (2)Data and Non-volatile Program and Data Memories; (3)Peripheral Features; (4)Special Microcontroller Features; (5)I/O and Packages; (6)Operating Voltages; (7)Typical Power Consumption.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
ATtiny2313-20SU |
Atmel |
8-bit Microcontrollers (MCU) 2kB Flash 0.128kB EEPROM 18 I/O Pins |
Data Sheet |
|
|
|||||||||||||
ATTINY2313-20SUR |
Atmel |
8-bit Microcontrollers (MCU) AVR 2KB FLSH 128B EE 128B SRAM 1UART 20P |
Data Sheet |
|
|
